Technical Parameters

Voltage: AC90V~240V/50-60Hz

Average lifespan: 1500 hours

Power:420W

Focus: Linear adjustment

Lamp: PHILIP HRI 350W

Dimmer: 0-100% linear adjustment

Color temperature:7500K

Strobe: Mechanical shutter 0.3-25 F.P.S

Ballast:E-ballast

Color/Pattern/Effect

Color:14 color + blank color wheel

Wash effect:Adjustable wash effects angle

Two prisms:8-facet and 16-facet prisms, bi-directional rotating at variable speeds, prism can be zoom in/out.

One Fixed gobo wheel: 15 fixed gobo + blank, rainbow and shade effect

One Rotating gobo wheel: 9 interchange gobo + blank, rotating and gobo position effect.

Beam angle:

                  Beam: 2.3°~ 10°

                  Gobo: 5°~ 22°

                   Wash: 5°~ 40°

Control system

*Control mode: DMX/ART-NET/RDM/Single Mode/Master/Slave mode

*Pan/Tilt speed: Pan 2.6sec/540°; Tilt 1.24sec /239°

*Channel: 20 in standard mode and 24 in extended mode

*Time function: Menu record overall operate time and working time of light and lamp

*Motor: 9pcs mute sound motor, 2pcs three phase motor, 16bit driver,

*IP set: Automatic charging battery, IP could be set without electricity

*Pan/Tilt: X axis 540°; Y axis 239°, automatically accurate positioning

*The menu display 16 million pixel color LCD touch screen; screen can display upright, inverted, and adjust the brightness of the background, in both English and Chinese can freely switch.

*The intelligent control of the cooling fan (the radiator is completely controlled by the state of the lamp and the requirements for the intelligent control to ensure the service life of the bulb and the normal working state).

*Electronic sensor detection reset error function, automatic correction work

*Modular structure for easy maintenance

Appearance parameter

High temperature Engineering plastic, IP20

Net weight: 22Kg

Body size: 41x27x64(cm)

Appearance parameter

High temperature Engineering plastic, IP20

Net weight: 22Kg

Body size: 41x27x64(cm)
